Specification
Accuracy | +/- 10 Kg |
Approach And Exit Roadways | 5 - 10 meters (min) |
Type Of Weighing | Static Weighing |
Load Cell Cable | 4 Core Shielded Cable |
Load Cells | 20 Ton / 30 Ton IP 68 Protected |
Direction of Weighing | One Direction |
Maximum Gross Weight of Vehicle | 100 Meter |
Operating Temperature Range | -10 Degree to + 60 Degree |
Material Of The Platform | Mild Steel (IS 2062) |
Maximum Capacity Each Scale | 60 Ton |
Platform Size | 600 mm X 2700 mm |
Nos of Load cell | 06 Set |
No of Axle | 2 & 3 Axle Pair |
Indicator Resolution | 10 Kg |
Static Accuracy | +/- 0.02% to +/- 0.05% |
Maximum Axle Weight | 40 Meter |
Non Linearity And Repeatability | 0.05% |
